ROHM 2SA1774EBTLR PNP Bipolar Transistor, 150 mA, 50 V, 3-Pin SOT-523

2SA1774EBTLR ROHM PNP Bipolar Transistor, 150 mA, 50 V, 3-Pin SOT-523
2SA1774EBTLR
2SA1774EBTLR
ET14077840
ET14077840
Bipolar Transistors
Bipolar Transistors
ROHM

Product Information

Minimum DC Current Gain:
120
Transistor Type:
PNP
Dimensions:
1.7 x 0.96 x 0.8mm
Mounting Type:
Surface Mount
Maximum Power Dissipation:
150 mW
Maximum Collector Emitter Saturation Voltage:
-0.5 V
Maximum Collector Base Voltage:
-60 V
Maximum Collector Emitter Voltage:
50 V
Maximum Operating Frequency:
100 MHz
Height:
0.8mm
Width:
0.96mm
Length:
1.7mm
Package Type:
SOT-523 (SC-89)
Number of Elements per Chip:
1
Maximum DC Collector Current:
150 mA
Maximum Emitter Base Voltage:
-6 V
Maximum Operating Temperature:
+150 °C
Pin Count:
3
Transistor Configuration:
Single
RoHs Compliant
Checking for live stock

This is PNP Bipolar Transistor 150 mA 50 V 3-Pin SOT-523 manufactured by ROHM. The manufacturer part number is 2SA1774EBTLR. It features up to 120 of minimum DC current gain. The transistor is a pnp type. The given dimensions of the product include 1.7 x 0.96 x 0.8mm. The product is available in surface mount configuration. Provides up to 150 mw maximum power dissipation. The product has a maximum -0.5 v collector emitter saturation voltage . Additionally, it has -60 v maximum collector base voltage. Whereas features a 50 v of collector emitter voltage (max). It carries 100 mhz of maximum operating frequency. In addition, the height is 0.8mm. Furthermore, the product is 0.96mm wide. Its accurate length is 1.7mm. The package is a sort of sot-523 (sc-89). It consists of 1 elements per chip. Moreover, it has a maximum DC collector current of 150 ma. It features a -6 v of maximum emitter base voltage. It has a maximum operating temperature of +150 °c. It contains 3 pins. The product offers single transistor configuration.

pdf icon
ESD Control Selection Guide V1(Technical Reference)
pdf icon
2SA1576UB-2SA1774EB 150mA 50V GP PNP Transistor(Technical Reference)

Reviews

  • Be the first to review.

FAQs

Yes. You can also search 2SA1774EBTLR on website for other similar products.
We accept all major payment methods for all products including ET14077840. Please check your shopping cart at the time of order.
You can order ROHM brand products with 2SA1774EBTLR directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Bipolar Transistors category are shipped in lowest possible time.
You will get a confirmation email regarding your order of ROHM 2SA1774EBTLR PNP Bipolar Transistor, 150 mA, 50 V, 3-Pin SOT-523. You can also check on our website or by contacting our customer support team for further order details on ROHM 2SA1774EBTLR PNP Bipolar Transistor, 150 mA, 50 V, 3-Pin SOT-523.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET14077840 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "ROHM" products on our website by using Enrgtech's Unique Manufacturing Part Number ET14077840.
Yes. We ship 2SA1774EBTLR Internationally to many countries around the world.
