This is 80 A Solid State Relay Zero Crossing Panel Mount SCR Triac 280 V ac Maximum Load manufactured by Kudom. The manufacturer part number is KSI240A80-L. The given dimensions of the product include 58.6 x 45.7 x 26.5mm. This is basically a industrial single phase relay. While its maximum load voltage is 280 v ac. Its output device includes scr, triac. Its load voltage range is about 48 → 280v ac . The product complies with all safety standards, such as ce, tuv, ul. Additionally, it has a minimum 90 v ac control voltage . Additionally, its off state leakage current is 5 ma . This product uses zero crossing switching mechanism. The terminal is a screw type. The product has -30 → +80°c of operating temperature range. Moreover, it has a typical 90 → 280 v ac control voltage range . Its accurate length is 58.6mm. The product has a maximum 20 ms turn on time . The product also provides special features, such as internal mov, internal rc, led indication, superior thermal performance, tvs protection circuit as option. It carries 80 a maximum load current. The product is available in panel mount configuration. The product comes in 45.7mm depth. In addition, the height is 26.5mm. The product has a maximum 280 v ac control voltage . It carries up to 48 v ac minimum load voltage.
For more information please check the datasheets.
