Dimensions:
44.5 x 57.3 x 22.6mm
Relay Type:
Solid State Relay
Capacitance:
8pF
Range:
Easy Pick
Maximum Load Voltage:
280 V ac
Output Device:
SCR
Load Voltage Range:
24 → 280V ac
Standards Met:
CE, CSA LR 38595, cULus Recognised E79183, EMC Compliant, EN 60950-1, EN 62314:2006, IEC, IEC 61000-4-2, IEC 61000-4-4, TUV, UL
Minimum Control Voltage:
3 V dc
Off State Leakage Current:
0.1mA rms
Switching Type:
Instantaneous
Maximum Operating Temperature:
+80°C
Terminal Type:
Screw
Control Voltage Range:
3 → 32 V dc
Operating Temperature Range:
-40 → +80°C
Minimum Load Current:
50 mA rms
Length:
44.5mm
Maximum Turn On Time:
1/2 cycle
Special Features:
Improved SEMS Screw & Washer, IP00, LED Input Status Indicator, Redesigned Housing with Anti-Rotation Barriers
Maximum Load Current:
25 A rms
Mounting Type:
Panel Mount
Series:
8413
Depth:
57.3mm
Height:
22.6mm
Minimum Operating Temperature:
-40°C
Maximum Control Voltage:
32 V dc
Number of Poles:
1
Minimum Load Voltage:
24 V ac
HTSUS:
8536.49.0055
RoHS Status:
RoHS Compliant
Termination Style:
Screw Terminal
Package / Case:
Hockey Puck
Voltage - Input:
3 ~ 32VDC
Load Current:
25 A
Output Type:
AC
edacadModel:
84134210K Models
edacadModelUrl:
/en/models/6025923
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Circuit:
SPST-NO (1 Form A)
standardLeadTime:
16 Weeks
Mounting Type:
Chassis Mount
Series:
-
Voltage - Load:
24 V ~ 280 V
Supplier Device Package:
-
Packaging:
Bulk
Base Product Number:
84134210
ECCN:
EAR99
