Photocoupler, MOSFET, 1a, DIP4

TLP3555-F- Photocoupler, MOSFET, 1a, DIP4
TLP3555(F)
Toshiba

Product Information

Dimensions:
4.58 x 6.4 x 3.65mm
Relay Type:
PhotoMOSFET
Capacitance:
250pF
Output Device:
MOSFET
Package Style:
DIP
Off State Leakage Current:
1 μA
Switching Type:
AC/DC
Maximum Operating Temperature:
+85°C
Terminal Type:
PCB Pin
Operating Temperature Range:
-40 → +85°C
Control Voltage Range:
Maximum of 48 V
Contact Configuration:
SPST
Length:
4.6mm
Maximum Turn On Time:
5ms
Special Features:
High Current Photorelays
Mounting Type:
Surface Mount
Depth:
6.4mm
Height:
3.7mm
Minimum Operating Temperature:
-40°C
Maximum Control Voltage:
48 V
Number of Poles:
1
RoHs Compliant
Checking for live stock

This is Photocoupler MOSFET 1a DIP4 manufactured by Toshiba. The manufacturer part number is TLP3555(F). The given dimensions of the product include 4.58 x 6.4 x 3.65mm. This is basically a photomosfet. It provides a 250pf of capacitance value. Its output device includes mosfet. Its package is of dip style . Additionally, its off state leakage current is 1 μa . This product uses ac/dc switching mechanism. It has a maximum operating temperature of +85°c. The terminal is a pcb pin type. The product has -40 → +85°c of operating temperature range. Moreover, it has a typical maximum of 48 v control voltage range . The contact is equipped with spst configuration. Its accurate length is 4.6mm. The product has a maximum 5ms turn on time . The product also provides special features, such as high current photorelays. The product is available in surface mount configuration. The product comes in 6.4mm depth. In addition, the height is 3.7mm. Whereas, the minimum operating temperature of the product is -40°c. The product has a maximum 48 v control voltage . It has equipped with 1 poles.
