Repetitive Peak Forward Blocking Voltage:
1000 to 1800V
Diameter:
42mm
Peak On-State Voltage:
2V
Dimensions:
42 (Dia.) x 14mm
Mounting Type:
Screw Mount
Repetitive Peak Reverse Voltage:
1000 to 1800V
Surge Current Rating:
10500A
Rated Average On-State Current:
795A
Repetitive Peak Off-State Current:
30mA
Minimum Operating Temperature:
-60 °C
Maximum Holding Current:
300mA
Maximum Gate Trigger Current:
150mA
Thyristor Type:
PCT
Maximum Operating Temperature:
+125 °C
Maximum Gate Trigger Voltage:
2.50V
HTSUS:
8541.30.0080
RoHS Status:
ROHS3 Compliant
Voltage - Off State:
1.8 kV
Voltage - Gate Trigger (Vgt) (Max):
2.5 V
Operating Temperature:
-60°C ~ 125°C
Package / Case:
TO-200AB, B-PuK
Current - Hold (Ih) (Max):
300 mA
REACH Status:
REACH Unaffected
Current - On State (It (RMS)) (Max):
1580 A
Package:
Box
Current - Off State (Max):
30 mA
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - Gate Trigger (Igt) (Max):
150 mA
Current - Non Rep. Surge 50, 60Hz (Itsm):
10500A @ 50Hz
Voltage - On State (Vtm) (Max):
2 V
Mounting Type:
Chassis Mount
Current - On State (It (AV)) (Max):
795 A
Series:
-
Supplier Device Package:
W91
SCR Type:
Standard Recovery
Base Product Number:
N0795
ECCN:
EAR99
