Maximum Continuous Drain Current:
±5 (PChannel) A, ±5.5 (NChannel) A
Width:
2.1mm
Maximum Drain Source Voltage:
20 V
Maximum Gate Threshold Voltage:
1.5V
Package Type:
DFN2020
Number of Elements per Chip:
2
Minimum Gate Threshold Voltage:
0.5V
Maximum Operating Temperature:
150 °C
Typical Gate Charge @ Vgs:
4 nC @ 4.5 V
Channel Type:
N, P
Length:
2.1mm
Pin Count:
8
Channel Mode:
Enhancement
Mounting Type:
Surface Mount
Maximum Power Dissipation:
2 W
Series:
UT6MA3
Maximum Gate Source Voltage:
±8 (N-Channel) V, ±8 (P-Channel) V
Height:
0.65mm
Minimum Operating Temperature:
-55 °C
Forward Diode Voltage:
1.2V
Maximum Drain Source Resistance:
76 mΩ
