Standard MOSFETs

RS3E180ATTB1 Standard MOSFETs
ROHM

Product Information

Maximum Continuous Drain Current:
18 A
Width:
4.05mm
Transistor Configuration:
Single
Maximum Drain Source Voltage:
30 V
Maximum Gate Threshold Voltage:
2.5V
Package Type:
SOP
Number of Elements per Chip:
1
Minimum Gate Threshold Voltage:
1V
Maximum Operating Temperature:
150 °C
Typical Gate Charge @ Vgs:
160 nC @ 10 V
Channel Type:
P
Length:
5.2mm
Pin Count:
8
Channel Mode:
Enhancement
Mounting Type:
Surface Mount
Maximum Power Dissipation:
2 W
Series:
RS3E180AT
Maximum Gate Source Voltage:
±20 V
Height:
1.6mm
Minimum Operating Temperature:
-55 °C
Forward Diode Voltage:
1.2V
Maximum Drain Source Resistance:
6.1 mΩ
RoHs Compliant
Checking for live stock

This is Standard MOSFETs manufactured by ROHM. The manufacturer part number is RS3E180ATTB1. While 18 a of maximum continuous drain current. Furthermore, the product is 4.05mm wide. The product offers single transistor configuration. It has a maximum of 30 v drain source voltage. The product carries 2.5v of maximum gate threshold voltage. The package is a sort of sop. It consists of 1 elements per chip. Whereas its minimum gate threshold voltage includes 1v. It has a maximum operating temperature of 150 °c. With a typical gate charge at Vgs includes 160 nc @ 10 v. The product is available in [Cannel Type] channel. Its accurate length is 5.2mm. It contains 8 pins. The product carries enhancement channel mode. The product is available in surface mount configuration. Provides up to 2 w maximum power dissipation. The product rs3e180at, is a highly preferred choice for users. It features a maximum gate source voltage of ±20 v. In addition, the height is 1.6mm. Whereas, the minimum operating temperature of the product is -55 °c. Its forward diode voltage is 1.2v . It provides up to 6.1 mω maximum drain source resistance.

pdf icon
Datasheet RS3E180ATTB1(Technical Reference)
