Nexperia PMN42XPEAX 3 P-channel MOSFET, -5.7 A, -20 V, 6-Pin SC-74, SOT457

PMN42XPEAX Nexperia 3 P-channel MOSFET, -5.7 A, -20 V, 6-Pin SC-74, SOT457
Nexperia

Product Information

Maximum Continuous Drain Current:
-5.7 A
Width:
1.7mm
Automotive Standard:
AEC-Q101
Transistor Configuration:
Single
Maximum Drain Source Voltage:
-20 V
Maximum Gate Threshold Voltage:
-1.25V
Package Type:
SC-74, SOT457
Number of Elements per Chip:
3
Minimum Gate Threshold Voltage:
-0.75V
Maximum Operating Temperature:
+150 °C
Typical Gate Charge @ Vgs:
11.5 nC @ 10 V
Channel Type:
P
Length:
3.1mm
Pin Count:
6
Channel Mode:
Enhancement
Mounting Type:
Surface Mount
Maximum Power Dissipation:
8330 mW
Maximum Gate Source Voltage:
12 V
Height:
1.1mm
Minimum Operating Temperature:
-55 °C
Maximum Drain Source Resistance:
64 mΩ
RoHs Compliant
Checking for live stock

This is 3 P-channel MOSFET -5.7 A -20 V 6-Pin SC-74 SOT457 manufactured by Nexperia. The manufacturer part number is PMN42XPEAX. While -5.7 a of maximum continuous drain current. Furthermore, the product is 1.7mm wide. The product complies with automotive standard - aec-q101. The product offers single transistor configuration. It has a maximum of -20 v drain source voltage. The product carries -1.25v of maximum gate threshold voltage. The package is a sort of sc-74, sot457. It consists of 3 elements per chip. Whereas its minimum gate threshold voltage includes -0.75v. It has a maximum operating temperature of +150 °c. With a typical gate charge at Vgs includes 11.5 nc @ 10 v. The product is available in [Cannel Type] channel. Its accurate length is 3.1mm. It contains 6 pins. The product carries enhancement channel mode. The product is available in surface mount configuration. Provides up to 8330 mw maximum power dissipation. It features a maximum gate source voltage of 12 v. In addition, the height is 1.1mm. Whereas, the minimum operating temperature of the product is -55 °c. It provides up to 64 mω maximum drain source resistance.
