Magnatec 2N6845 P-channel MOSFET, 4 A, 100 V, 3-Pin TO-39

2N6845 Magnatec  P-channel MOSFET, 4 A, 100 V, 3-Pin TO-39
Magnatec

Product Information

Maximum Drain Source Voltage:
100 V
Typical Gate Charge @ Vgs:
16.3 nC @ 10 V
Mounting Type:
Through Hole
Channel Mode:
Enhancement
Maximum Power Dissipation:
20 W
Maximum Gate Source Voltage:
-20 V, +20 V
Maximum Gate Threshold Voltage:
4V
Channel Type:
P
Width:
9.4mm
Length:
9.4mm
Maximum Drain Source Resistance:
690 mΩ
Package Type:
TO-39
Number of Elements per Chip:
1
Minimum Operating Temperature:
-55 °C
Maximum Continuous Drain Current:
4 A
Transistor Material:
Si
Height:
4.57mm
Maximum Operating Temperature:
+150 °C
Pin Count:
3
Transistor Configuration:
Single
Checking for live stock

This is P-channel MOSFET 4 A 100 V 3-Pin TO-39 manufactured by Magnatec. The manufacturer part number is 2N6845. It has a maximum of 100 v drain source voltage. With a typical gate charge at Vgs includes 16.3 nc @ 10 v. The product is available in through hole configuration. The product carries enhancement channel mode. Provides up to 20 w maximum power dissipation. It features a maximum gate source voltage of -20 v, +20 v. The product carries 4v of maximum gate threshold voltage. The product is available in [Cannel Type] channel. Furthermore, the product is 9.4mm wide. Its accurate length is 9.4mm. It provides up to 690 mω maximum drain source resistance. The package is a sort of to-39. It consists of 1 elements per chip. Whereas, the minimum operating temperature of the product is -55 °c. While 4 a of maximum continuous drain current. The transistor is manufactured from highly durable si material. In addition, the height is 4.57mm. It has a maximum operating temperature of +150 °c. It contains 3 pins. The product offers single transistor configuration.
