Category:
Power MOSFET
Dimensions:
10.67 x 9.65 x 4.83mm
Maximum Continuous Drain Current:
180 A
Transistor Material:
Si
Width:
9.65mm
Transistor Configuration:
Single
Maximum Drain Source Voltage:
100 V
Maximum Gate Threshold Voltage:
2.5V
Package Type:
D2PAK (TO-263)
Number of Elements per Chip:
1
Minimum Gate Threshold Voltage:
1V
Maximum Operating Temperature:
+175 °C
Typical Gate Charge @ Vgs:
87 nC @ 4.5 V
Channel Type:
N
Typical Input Capacitance @ Vds:
11360 pF@ 50 V
Length:
10.67mm
Pin Count:
3
Typical Turn-Off Delay Time:
110 ns
Mounting Type:
Surface Mount
Channel Mode:
Enhancement
Maximum Power Dissipation:
370 W
Series:
HEXFET
Maximum Gate Source Voltage:
-16 V, +16 V
Height:
4.83mm
Typical Turn-On Delay Time:
74 ns
Minimum Operating Temperature:
-55 °C
Maximum Drain Source Resistance:
4 mΩ
