Voltage Sensitivity:
Overvoltage, Undervoltage
Dimensions:
72 x 35 x 90mm
Voltage Sensing Range:
220 → 480V ac
Width:
35mm
Electrical Phase:
3
Standards Met:
CE, CSA, RoHS Compliant, UL
Maximum Operating Temperature:
+50°C
Terminal Type:
Screw
Time Delay:
0.1 → 10s
Minimum Voltage Sensed:
220V ac
Operating Temperature Range:
+50°C
Monitoring Application:
Phase, Voltage
Maximum Voltage Sensed:
480V ac
Contact Configuration:
DPDT
Length:
72mm
Phase Sensitivity:
Phase Asymmetry, Phase Failure, Phase Sequence
Better World Verification:
Green Premium
Better World Product:
Yes
Mounting Type:
DIN Rail
Series:
Harmony Control
Height:
90mm
Minimum Operating Temperature:
-20°C
RoHS Status:
RoHS non-compliant
Operating Temperature:
-20°C ~ 50°C
Type:
Voltage Asymmetry, Voltage Sensing AC, Phase Loss, Phase Sequence
REACH Status:
REACH Affected
Output Type:
Relay
Trip Range:
220 ~ 480V AC
Trip Status:
Energized High/Low
Manufacturer:
Schneider Electric
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Circuit:
DPDT (2 Form C)
Contact Rating @ Voltage:
5A @ 250VAC/250VDC
standardLeadTime:
5 Weeks
Delay Time:
0.1 Sec ~ 10 Sec
Mounting Type:
DIN Rail
Series:
Harmony
Packaging:
Box
Voltage - Supply:
220 ~ 480VAC
