12V Coil Non-Latching Relay SPDT, 6A Switching Current DIN Rail

RV8H-L-AD12 12V Coil Non-Latching Relay SPDT, 6A Switching Current DIN Rail
RV8H-L-AD12 12V Coil Non-Latching Relay SPDT, 6A Switching Current DIN Rail
Idec

Product Information

Switching AC Voltage:
400 V ac
Switching DC Voltage:
125 V dc
Minimum Operating Temperature:
-40°C
Series:
RV8
Switching Current:
6 A
Coil Voltage:
12 V dc
Coil Resistance:
800Ω
Height:
75mm
Width:
6.1 mm
Length:
88mm
Standards/Approvals:
RoHS
Contact Material:
Silver Nickel Alloy
Contact Configuration:
SPDT
Product Type:
Interface Relay
Maximum Operating Temperature:
70°C
Terminal Type:
Screw
Mount Type:
DIN Rail
Must Release Voltage:
840 mVAC/DC
RoHS Status:
ROHS3 Compliant
Coil Voltage:
12VAC/DC
Termination Style:
Screw Terminal
REACH Status:
REACH Affected
Operating Temperature:
-40°C ~ 70°C
Approval Agency:
CE, cULus
Coil Resistance:
755 Ohms
Coil Current:
15.5 mA
Coil Type:
Non Latching
title:
RV8H-L-AD12
Seal Rating:
-
Must Operate Voltage:
10.8 VAC/DC
Relay Type:
General Purpose
Load - Max Switching:
2400VA, 750W
Contact Form:
SPDT (1 Form C)
Moisture Sensitivity Level (MSL):
Not Applicable
Operate Time:
15 ms
Qualification:
-
standardLeadTime:
27 Weeks
Contact Rating (Current):
6 A
Features:
Socket Included
Mounting Type:
DIN Rail
Grade:
-
Series:
RV8
Switching Voltage:
400VAC, 125VDC - Max
Release Time:
20 ms
Packaging:
Bulk
Coil Insulation:
-
Base Product Number:
RV8H-L
Contact Material:
Silver Nickel (AgNi), Gold (Au)
RoHs Compliant
Checking for live stock

This is 12V Coil Non-Latching Relay SPDT 6A Switching Current DIN Rail manufactured by Idec. The manufacturer part number is RV8H-L-AD12. Whereas, the minimum operating temperature of the product is -40°c. The product rv8, is a highly preferred choice for users. It is integrated with 6 a switching current. The coil voltage of the product is 12 v dc. It holds up to 800ω coil resistance. In addition, the height is 75mm. Furthermore, the product is 6.1 mm wide. Its accurate length is 88mm. The product is made from sturdy silver nickel alloy materials. The contact is equipped with spdt configuration. interface relay is a versatile product designed to provide user-defined applications. It has a maximum operating temperature of 70°c. The terminal is a screw type. It has a din rail type mount . While the must release voltage is a 840 mvac/dc. The product is rohs3 compliant. The coil voltage of the product is 12vac/dc. Moreover, it has screw terminal terminal style. In addition, it is reach affected. The product has -40°c ~ 70°c operating temperature range. It is approved by ce, culus. It holds up to 755 ohms coil resistance. It has a coil current of 15.5 ma. The coil is a non latching type. On the other hand, 10.8 vac/dc is the given crucial/must operating voltage. This is basically a general purpose. It also has a spdt (1 form c) contact form. Its typical moisture sensitivity level is not applicable. The operating time of the product is 15 ms. It has a long 27 weeks standard lead time. It has a contact current rating of 6 a. The splendid features of the product include socket included. The product is available in din rail configuration. The product's switching voltage is 400vac, 125vdc - max. While 20 ms is its release time. In addition, bulk is the available packaging type of the product. Moreover, it corresponds to rv8h-l, a base product number of the product. The product is made from sturdy silver nickel (agni), gold (au) materials.

pdf icon
Datasheet - RV8H-L-AD12(Technical Reference)
