Shell Size, Connector Layout:
4 (DC, C) High Density
Flange Feature:
Mating Side, Female Screwlock (4-40)
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-40°C ~ 85°C
Connector Style:
D-Sub, High Density
Contact Finish Thickness:
30.0µin (0.76µm)
Dielectric Material:
Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Number of Positions:
62
title:
09564625813
REACH Status:
REACH Unaffected
edacadModel:
09564625813 Models
Number of Rows:
3
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/4339019
Voltage Rating:
-
Wire Gauge:
-
Contact Form:
Stamped
Connector Type:
Plug, Male Pins
Contact Finish:
Gold or Gold-Palladium
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Termination:
Solder
standardLeadTime:
13 Weeks
Current Rating (Amps):
2A
Backset Spacing:
0.350" (8.89mm)
Ingress Protection:
-
Features:
Board Lock, Grounding Indents
Mounting Type:
Through Hole, Right Angle
Color:
-
Series:
-
Shell Material, Finish:
Steel, Nickel Plated
Packaging:
Bulk
Contact Type:
Signal
Contact Material:
Copper Alloy
ECCN:
EAR99
Housing Material:
Resin
Number of Contacts:
62
Orientation:
Angled
D-Sub Shell Size:
4
Series:
D Sub
Minimum Operating Temperature:
-40.00?C
Mounting Hardware:
Flange
Contact Gender:
Male
Connector Type D:
D-Sub
Current:
2A
Standards/Approvals:
UL 94 V-0
Contact Plating:
Tin over Nickel
Contact Material:
Copper Alloy
Termination Type:
Solder Wave
Product Type:
Connector
Connector Gender:
Male
Maximum Operating Temperature:
85.00?C
Mount Type:
PCB
