NXP 74HC4049D,652, Logic Level Translator, Hex Inverting High to Low Level Shifter, 16-Pin SOIC

74HC4049D-652 NXP 74HC4049D,652, Logic Level Translator, Hex Inverting High to Low Level Shifter, 16-Pin SOIC
Nexperia

Product Information

Maximum Low Level Output Current:
5.2mA
Dimensions:
10 x 4 x 1.45mm
Mounting Type:
Surface Mount
Maximum Propagation Delay Time @ Maximum CL:
130 ns @ 50 pF
Minimum Operating Supply Voltage:
2 V
Logic Function:
Hex Inverting High to Low Level Shifter
Output Type:
Single Ended
Maximum High Level Output Current:
-5.2mA
Package Type:
SOIC
Logic Family:
74HC
Minimum Operating Temperature:
-40 °C
Maximum Operating Supply Voltage:
6 V
Maximum Operating Temperature:
+125 °C
Pin Count:
16
Propagation Delay Test Condition:
50pF
RoHs Compliant
Checking for live stock

This is NXP Logic Level Translator Hex Inverting High to Low Level Shifter 16-Pin SOIC manufactured by Nexperia. The manufacturer part number is 74HC4049D,652. On the other hand, it is featured with 5.2ma of max. low level output current. The given dimensions of the product include 10 x 4 x 1.45mm. The product is available in surface mount configuration. It provides up to 130 ns @ 50 pf maximum propagation delay time. While its minimum operating supply voltage is 2 v. The primary function of logic includes hex inverting high to low level shifter. Furthermore, it has asingle ended output. While a -5.2ma of maximum high level output current. The package is a sort of soic. The logic family is 74hc. Whereas, the minimum operating temperature of the product is -40 °c. It has 6 v maximum operating supply voltage. It has a maximum operating temperature of +125 °c. It contains 16 pins. Features 50pf of propagation delay test condition.

pdf icon
74HC4049, Hex Inverting HIGH-to-LOW Level Shifter(Technical Reference)
pdf icon
ESD Control Selection Guide V1(Technical Reference)
