Wurth WE-PD2 Series Unshielded Wire-wound SMD Inductor with a Ferrite Core, 220 μH ±10% 420mA Idc

Enrgtech Part No: ET13908039
|
Manufacturer Part No:
744774222
|
Manufacturer: Wurth Elektronik

744774222 Wurth WE-PD2 Series Unshielded Wire-wound SMD Inductor with a Ferrite Core, 220 μH ±10% 420mA Idc

Product Information

Maximum DC Resistance:

1.57Ω

Dimensions:

5.8 x 5.2 x 4.5mm

Shielded:

Series:

WE-PD2

Length:

5.8mm

Height:

4.5mm

Maximum DC Current:

420mA

Depth:

5.2mm

Core Material:

Ferrite

Inductance:

220 μH

Maximum Self Resonant Frequency:

5MHz

Maximum Operating Temperature:

+125°C

Checking for live stock

This is Wurth WE-PD2 Series Unshielded Wire-wound SMD Inductor with a Ferrite Core 220 μH ±10% 420mA Idc manufactured by Wurth Elektronik. The manufacturer part number is 744774222. It allows up to 1.57ω maximum DC resistance. The given dimensions of the product include 5.8 x 5.2 x 4.5mm. Shielding Options no. The product we-pd2, is a highly preferred choice for users. Its accurate length is 5.8mm. In addition, the height is 4.5mm. While it carries 420ma of maximum DC current. The product comes in 5.2mm depth. The core is manufactured from highly durable and reliable ferrite materials. The product has a 220 μh inductance value. It provides 5mhz of maximum self-resonant frequency. It has a maximum operating temperature of +125°c. It features ±10% of tolerance value. Whereas, the minimum operating temperature of the product is -40°c.
