Fire Behaviour:
Oil Resistant, Low Smoke Zero Halogen (LSZH), CPR Euroclass rating, IEC 60332-1, Flame Retardant to UL1581 VW-1, IEC 60332-1-2
Conductor Material:
Tin Copper Wire
Cable Type:
Flat
Number of Conductors:
16
Core Strands:
7
Screened/Unscreened:
Unscreened
American Wire Gauge:
28AWG
Standards/Approvals:
REACH, UL1581 VW-1, IEC 60227-5, DEF STAN 61-12 Part 6, CENELEC HD21.5, BASEC, VD0281-5, VD2050, BS EN13062, TS 9760 HD 21.5.S3, RoHS, BS4109, CSA TEW, IEC60332-1, BS4808, IEC 60228 Css 5, HAR, UL, IEC 60332-1-2, DEF STAN 61-12 Part 29/1, ISO9001
Voltage:
300 V
Minimum Operating Temperature:
-20°C
Pitch:
1.27mm
Hi-Flex:
Yes
Product Type:
Ribbon Cable
Maximum Operating Temperature:
105°C
Cable Length:
500m
