Fire Behaviour:
Low Smoke Zero Halogen (LSZH), CPR Euroclass rating, Flame Retardant to IEC 60332-1-2, Flame resistant to UL1581 VW-1 and IEC60332-1
Conductor Material:
Tin Copper Wire
Cable Type:
Flat
Number of Conductors:
64
Core Strands:
7
Screened/Unscreened:
Unscreened
American Wire Gauge:
28AWG
Standards/Approvals:
REACH, IEC60332-1, VD0281-5, IEC 60332-1-2, BS EN13062, Mil Spec, IEC 60228 Css 5, UL, HAR, IEC 60227-5, CENELEC HD21.5, VD0295, DEF STAN, BS4808, TS 9760 HD 21.5.S3, CE, BASEC, VD2050, BS4109, UL1581 VW-1, ISO9001, RoHS
Voltage:
300 V
Minimum Operating Temperature:
-20°C
Pitch:
1.27mm
Hi-Flex:
Yes
Product Type:
Ribbon Cable
Maximum Operating Temperature:
105°C
Cable Length:
30m
