DiodesZetex AP2511MP-13, Dual Power Distribution Switch, High Side, 135mΩ, 2.7 V min. 8-Pin, MSOP 8EP

AP2511MP-13 DiodesZetex , Dual Power Distribution Switch, High Side, 135mΩ, 2.7 V min. 8-Pin, MSOP 8EP
DiodesZetex

Product Information

Number of Outputs:
2
Dimensions:
3.1 x 3.1 x 0.95mm
Mounting Type:
Surface Mount
Maximum Operating Current:
4.6A
Minimum Operating Temperature:
-40 °C
Package Type:
MSOP 8EP
Power Switch Topology:
High Side
Switch On Resistance:
135mΩ
Maximum Operating Supply Voltage:
5.5 V
Maximum Operating Temperature:
+85 °C
Pin Count:
8
RoHs Compliant
Checking for live stock

This is Dual Power Distribution Switch High Side 135mΩ 2.7 V min. 8-Pin MSOP 8EP manufactured by DiodesZetex. The manufacturer part number is AP2511MP-13. Additionally, the product is supplied with 2 outputs. The given dimensions of the product include 3.1 x 3.1 x 0.95mm. The product is available in surface mount configuration. Moreover, the product needs a maximum 4.6a operating current . Whereas, the minimum operating temperature of the product is -40 °c. The package is a sort of msop 8ep. It has a high side power switch topology . In addition, it has about 135mω switch on resistance . It has 5.5 v maximum operating supply voltage. It has a maximum operating temperature of +85 °c. It contains 8 pins.

pdf icon
AP2501/AP2511, 2.5A Single Channel Current-Limited Power Switch(Technical Reference)
pdf icon
ESD Control Selection Guide V1(Technical Reference)
