Program Capacity:
368bit
Number of Inputs:
16
Communication Port Type:
Serial, USB
Width:
71.2 mm
Supply Voltage:
24 V dc
Input Type:
Digital
Output Type:
Solid State
Product Type:
Logic Module
Maximum Operating Temperature:
55°C
Programming Language Used:
Ladder Logic
Number of Outputs:
10
Minimum Operating Temperature:
-20°C
Length:
100mm
Standards/Approvals:
IEC/EN 61000-6-3, IEC/EN 61000-6-4, IEC/EN 61131-2 (Open equipment) IEC/EN 61131-2 (Zone B) IEC/EN 61000-6-2
Number of Communication Ports:
2
Mount Type:
DIN Rail
Output Current:
12A
Series:
Millenium 3
Depth:
68mm
Battery Backup:
Yes
Display Included:
Yes
HTSUS:
8537.10.9170
RoHS Status:
RoHS Compliant
Number of Outputs and Type:
10 - PWM (4), Solid State (6)
Operating Temperature:
-20°C ~ 70°C
Memory Size:
368 Bits/200 Words
Approval Agency:
CE, CSA, GL, UL
Mounting Type:
Chassis Mount, DIN Rail
Number of Characters Per Row:
18, 18, 18, 18
REACH Status:
REACH Unaffected
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Communications:
-
standardLeadTime:
3 Weeks
Software:
M3 Soft
Display Type:
LCD - White Characters, Backlight
Ingress Protection:
IP40
Features:
Battery Backup (Lithium)
Weight:
-
Number of Inputs and Type:
16 - Digital (10), Analog/Digital (6)
Series:
Millenium 3, XD26
Voltage - Supply:
24VDC
Expandable:
Expandable
ECCN:
EAR99
