Phoenix Contact COMBICON MC, 3.5mm Pitch, 2 Way PCB Terminal Block Header

1789384 Phoenix Contact COMBICON MC, 3.5mm Pitch, 2 Way PCB Terminal Block Header
Phoenix Contact

Product Information

Current Rating:
8.0A
Mounting Type:
Through Hole
Voltage Rating:
250.0 V
Series:
MC 1.5/ 2-GF-3.5 P20 THR
Body Orientation:
Right Angle
Termination Method:
Solder
Pluggable Terminal Block Type:
Header
Number of Rows:
1
Pitch:
3.5mm
Number of Contacts:
2
Contact Material:
Tin
HTSUS:
8536.69.4040
Termination Style:
Solder
Housing Material:
Liquid Crystal Polymer (LCP)
Operating Temperature:
-40°C ~ 100°C
Screw Size:
-
Wire Strip Length:
-
Type:
Header, Male Pins, Shrouded (4 Side)
Number of Positions:
2
Contact Tail Length:
0.079" (2.00mm)
Wire Gauge or Range - mm²:
-
Plug Wire Entry:
-
Insulation Height:
0.272" (6.91mm)
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Current - IEC:
8A
Wire Gauge or Range - AWG:
-
Voltage - UL:
300 V
Torque - Screw:
-
standardLeadTime:
8 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
160 V
Ingress Protection:
-
Features:
Flange
Mounting Type:
Through Hole
Color:
Black
Series:
COMBICON MC
Positions Per Level:
2
Header Orientation:
90°, Right Angle
Current - UL:
8 A
Pitch:
0.138" (3.50mm)
Number of Levels:
1
ECCN:
EAR99
Contact Material:
Copper Alloy
RoHs Compliant
Checking for live stock

This is COMBICON MC 3.5mm Pitch 2 Way PCB Terminal Block Header manufactured by Phoenix Contact. The manufacturer part number is 1789384. The product has a current rating of 8.0a. The product is available in through hole configuration. Moreover, the product has a nominal 250.0 v voltage rating. The product mc 1.5/ 2-gf-3.5 p20 thr, is a highly preferred choice for users. It has right angle body orientation. It allows solder termination method. It comes in 1 of rows. Moreover, the product is 3.5mm. The product contains 2 contacts. The product is made from sturdy tin materials. It is assigned with possible HTSUS value of 8536.69.4040. Moreover, it has solder terminal style. The product also features robust liquid crystal polymer (lcp) housing material. The product has -40°c ~ 100°c operating temperature range. It comes in header, male pins, shrouded (4 side) configuration. The product carries possible position value of 2. The typical tail length of the product is [Contact Tail Lenght]. 0.272" (6.91mm) of insulation height. It carries ul94 v-0 of material flammability rating. It is shipped in bulk package . An IEC current of 8a. While 300 v is the typical voltage of the product. It has a long 8 weeks standard lead time. The mating finish of the contact is tin. The nominal voltage of the product is 160 v. The splendid features of the product include flange. It has a classic black colour. The product combicon mc, is a highly preferred choice for users. It has 2 positions each level. The product has a 90°, right angle of a header orientation. The typical current includes 8 a. Moreover, the product is 0.138" (3.50mm). The product carries 1 levels. The product is designated with the ear99 code number. The product is made from sturdy copper alloy materials.

pdf icon
Datasheet(Technical Reference)
pdf icon
Mult Dev Pkg Chgs 10/Jul/2023(PCN Packaging)
