Amphenol FCI 20021311-00010T4LF

20021311-00010T4LF Amphenol FCI
20021311-00010T4LF
20021311-00010T4LF
ET11894889
ET11894889
Amphenol FCI

Product Information

The Amphenol FCI 20021311-00010T4LF PCB Connector is a high-performance, low-profile solution for seamless circuit board connections. Made with durable construction and precise engineering, this PCB Connector delivers reliable and efficient connectivity for typical electronic applications.

Shrouded/Unshrouded:
Shrouded
Series:
Minitek127
Body Orientation:
Vertical
Number of Rows:
2
Pitch:
1.27mm
Number of Contacts:
10
Manufacturer Standard Lead Time:
8 Weeks
Style:
Board to Board
Detailed Description:
10 Position Receptacle Connector 0.050" (1.27mm) Through Hole Gold
Operating Temperature:
-40°C ~ 105°C
Contact Finish Thickness - Post:
100.0µin (2.54µm)
Number of Positions:
10
Contact Finish - Mating:
Gold
Insulation Height:
0.173" (4.40mm)
Contact Finish Thickness - Mating:
10.0µin (0.25µm)
Contact Length - Post:
0.094" (2.40mm)
Applications:
General Purpose, Industrial, Telecommunications
Number of Rows:
2
Standard Package:
86
Contact Shape:
Square
Manufacturer:
Amphenol FCI
Insulation Color:
Black
Material Flammability Rating:
UL94 V-0
Row Spacing - Mating:
0.050" (1.27mm)
Connector Type:
Receptacle
Number of Positions Loaded:
All
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Push-Pull
Termination:
Solder
Pitch - Mating:
0.050" (1.27mm)
Mounting Type:
Through Hole
Series:
Minitek 127® 20021311
Packaging:
Tube
Contact Type:
Female Socket
Contact Finish - Post:
Tin
Other Names:
10122289-310000TLF 2002131100010T4LF 609-3754
Insulation Material:
Plastic
Contact Material:
Phosphor Bronze
RoHs Compliant
Checking for live stock

The Amphenol FCI Board-to-Board Vertical 10 Position Receptacle Connector, identified as part number 20021311-00010T4LF, is a highly versatile interconnect solution designed for use in a wide range of electronic devices. The connector is engineered to provide reliable and robust connectivity between PCBs, ensuring optimal performance and signal integrity in demanding applications.

Features of 20021311-00010T4LF Receptacle Connector:

The 20021311-00010T4LF connector boasts a range of advanced features that make it an ideal choice for high-performance applications. These features include:

  • 10-position receptacle connector: The connector features ten individual pins arranged in a single row, allowing for easy and reliable connections between PCBs.
  • Vertical orientation: The connector is designed for vertical mounting, which helps to conserve space on the PCB and improve overall system efficiency.
  • High-speed data transfer: The connector is capable of supporting high-speed data transfer rates of up to 10 Gbps, making it suitable for use in a range of high-bandwidth applications.
  • Robust construction: The connector is constructed from high-quality materials, including durable thermoplastic housing and gold-plated contacts, ensuring long-term reliability and performance.
  • RoHS compliant: The connector is fully RoHS compliant, meaning that it meets all relevant environmental and safety standards.

Benefits of 20021311-00010T4LF Receptacle Connector:

The 20021311-00010T4LF connector offers a range of benefits for designers and engineers working in a range of industries, including:

  • Easy integration: The connector's simple design and vertical orientation make it easy to integrate into a range of PCB layouts, reducing design time and improving overall system efficiency.
  • High-speed data transfer: The connector's ability to support high-speed data transfer rates up to 10 Gbps ensures that it can handle even the most demanding data transfer requirements.
  • Reliability: The connector's robust construction ensures long-term reliability, reducing the risk of system failures and minimizing maintenance requirements.
  • RoHS compliance: The connector's full RoHS compliance means that it is environmentally friendly and meets all relevant safety standards.

pdf icon
Datasheet - 20021311-00010T4LF(Technical Reference)
pdf icon
BTB Design 25/Feb/2013(PCN Design/Specification)
pdf icon
BTB header/receptacle 25/Feb/2013(PCN Design/Specification)
pdf icon
20021311 Drawing(Datasheets)
pdf icon
Minitek 127 Catalog(Datasheets)
pdf icon
154 (UK2011-EN PDF)(Catalog Page)
