Screened/Unscreened:
Screened
Standards Met:
CE Certified, DIN EN 50290-2-22, DIN VDE 0295 Class 5, EN 60228 Class 5, IEC 60332-1, IEC Certified, REACH EC 1907/2006
Conductor Resistance:
19.5 Ω/km @ 20°C
Screen Type:
Tinned Copper Braid
Conductor Material:
Copper
Maximum Operating Temperature:
+70 (Dynamic) °C, +80 (Static) °C
Voltage Rating:
300/500 V ac
Fire Behaviour:
IEC 60332-1
Core Strands:
30/0.20 mm
Sheath Colour:
Grey
Length:
100m
Insulation Material:
PVC
Minimum Operating Temperature:
-40 (Static) °C, -30 (Dynamic) °C
Number of Cores:
12
Cross Sectional Area:
1 mm²
Outer Diameter:
1.26mm
Minimum Bend Radius:
7.56 (Static) mm, 25.2 (Dynamic) mm
Sheath Material:
Polyvinyl Chloride PVC
Ratings:
-
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Conductor Strand:
30/0.0079"
Operating Temperature:
-40°C ~ 80°C
Usage:
Industrial
title:
470121CY GE033
Number of Conductors:
12
REACH Status:
REACH Unaffected
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Wire Gauge:
17 AWG
Shield Type:
Braid
Jacket (Insulation) Thickness:
0.0492" (1.250mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
16.40' (5.00m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
Shield Coverage:
80%
Features:
Chemical Resistant, Oil Resistant, UV Resistant
Jacket (Insulation) Diameter:
0.542" (13.76mm)
Conductor Material:
Copper, Bare
Series:
Pro-Met®
Cable Type:
Multi-Conductor
Packaging:
Bulk
Voltage:
300 V
Shield Material:
Copper, Tinned
ECCN:
EAR99
Base Product Number:
470121CY
Jacket Color:
Gray
