Screened/Unscreened:
Screened
Maximum Operating Temperature:
(Dynamic) +70 °C, (Static) +80°C
Standards Met:
CE Certified, DIN EN 50290-2-22, DIN VDE 0295 Class 5, EN 60228 Class 5, IEC 60332-1, IEC Certified, REACH EC 1907/2006
Control Cable Type:
CY
Screen Type:
Tinned Copper Braid
Conductor Material:
Copper
Series:
Pro-Met
Voltage Rating:
300/500 V ac
Fire Behaviour:
Flame Retardant
Core Strands:
28/0.25 mm
Sheath Colour:
Transparent
Length:
50m
Insulation Material:
PVC
Minimum Operating Temperature:
(Dynamic) -30 °C, (Static) -40°C
Number of Cores:
7
Conductor Resistance:
13.5 Ω/km
Cross Sectional Area:
1.5 mm²
Outer Diameter:
1.52mm
Minimum Bend Radius:
30.4 (Dynamic) mm, 9.12 (Static) mm
Sheath Material:
PVC
Ratings:
-
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Conductor Strand:
28/0.0098"
Operating Temperature:
-40°C ~ 80°C
Usage:
Industrial
Number of Conductors:
7
REACH Status:
REACH Unaffected
Package:
Spool
Wire Gauge:
15 AWG
Shield Type:
Braid
Jacket (Insulation) Thickness:
0.0433" (1.100mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
164.0' (50.0m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
25 Weeks
Shield Coverage:
80%
Features:
Chemical Resistant, Oil Resistant, UV Resistant
Jacket (Insulation) Diameter:
0.458" (11.63mm)
Conductor Material:
Copper, Bare
Series:
Pro-Met®
Cable Type:
Multi-Conductor
Voltage:
300 V
Shield Material:
Copper, Tinned
ECCN:
EAR99
Base Product Number:
470715CY
Jacket Color:
Clear
