American Wire Gauge:
22 AWG
Screened/Unscreened:
Screened
Number of Cores:
10
Outer Diameter:
6.32mm
Standards Met:
CE, CSA, UL
Core Strands:
19/0.16 mm
Maximum Operating Temperature:
+80°C
Drain Wire:
Yes
Voltage Rating:
300 V
Minimum Bend Radius:
10 x Diameter
Fire Behaviour:
Halogen Free
Length:
30m
Sheath Material:
mPPE
Control Cable Type:
ECO
Screen Type:
Foil and Braid
Conductor Material:
Tinned Copper
Series:
Ecogen Ecocable Mini
Sheath Colour:
Grey
Cross Sectional Area:
0.38 mm²
Minimum Operating Temperature:
-40°C
Insulation Material:
MPPE
Manufacturer Standard Lead Time:
2 Weeks
Ratings:
ISO 10993, UL Style 21460
Operating Temperature:
-40°C ~ 80°C
Number of Conductors:
10
Conductor Strand:
19/34
Jacket (Insulation) Material:
Polyphenylene Ether, Modified (mPPE)
Standard Package:
1
Manufacturer:
Alpha Wire
Jacket (Insulation) Thickness:
0.015" (0.38mm)
Wire Gauge:
22 AWG
Shield Type:
Foil, Braid
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
100.0' (30.5m)
Conductor Insulation:
Polyphenylene Ether, Modified (mPPE)
Shield Coverage:
100%
Features:
Biological Compatibility, Drain Wire, Rip Cord
Jacket (Insulation) Diameter:
0.249" (6.32mm)
Conductor Material:
Copper, Tinned
Series:
EcoCable® Mini
Cable Type:
Multi-Conductor
Voltage:
300V
Shield Material:
Suprashield®; Copper, Tinned
Jacket Color:
Slate
