Hazardous Area Certification:
No
Jacket Colour:
Grey
Minimum Operating Temperature:
-35°C
Conductor Material:
Tin Copper Wire
Series:
5126
Fire Behaviour:
EN 60332-1, EN
Core Strands:
6
Screened/Unscreened:
Screened
American Wire Gauge:
22AWG
Standards/Approvals:
UL, RoHS, IEC, CSA, CE
Jacket Material:
Polyvinyl Chloride
Cable CSA:
0.34 mm²
Product Type:
Multicore Cable
Maximum Operating Temperature:
105°C
Cable Length:
100ft
Manufacturer Standard Lead Time:
2 Weeks
Ratings:
ISO 10993
Operating Temperature:
-35°C ~ 105°C
Usage:
Communication, Control
Number of Conductors:
12 (6 Pair Twisted)
Conductor Strand:
7/30
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Standard Package:
5
Manufacturer:
Alpha Wire
Jacket (Insulation) Thickness:
0.032" (0.81mm)
Wire Gauge:
22 AWG
Shield Type:
Foil, Braid
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
100.0' (30.5m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
Shield Coverage:
100%, 70%
Features:
Biological Compatibility, Drain Wire, Rip Cord
Jacket (Insulation) Diameter:
0.344" (8.74mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® 1
Cable Type:
Multi-Pair
Voltage:
300V
Shield Material:
Suprashield®; Copper, Tinned
Jacket Color:
Slate
