Automotive Standard:
AEC-Q100 Grade 2
Data Bus Width:
16bit
Instruction Set Architecture:
ARM
Series:
SAMA7D6
Maximum Clock Frequency:
1GHz
Height:
1.2mm
Device Core:
ARM Cortex A7
Width:
14 mm
Length:
14mm
Package Type:
TFBGA
Interface Type:
USB, SDIO, SPI, RGB 8Bit, MIPI-DSI, LVDS, I2C, CAN FD, MMC, Ethernet, NAND, QSPI
Minimum Operating Temperature:
-40°C
Standards/Approvals:
IEEE 802.1AS, IEEE 802.1Qav, FIPS 197, IEEE 802.3az, IEEE 1588, FIPS 46-3, FIPS 140-2, FIPS 140-3, NIST SP 800-22, AEC-Q100, FIPS 180-2
Number of Cores:
1
Product Type:
Microcontroller
Maximum Operating Temperature:
125°C
Pin Count:
427
Mount Type:
Surface
