This is 16bit 78K0R Microcontroller 20MHz 256 kB Flash 80-Pin LFQFP manufactured by Renesas Electronics. The manufacturer part number is UPD78F1156AGK-GAK-AX. The given dimensions of the product include 12 x 12 x 1.4mm. Moreover, it comprises 3 I2C channels. Furthermore, the product is 12mm wide. In addition, 256 kb is the program memory size. Furthermore, it is composed of 1 PWM units. The product has typical 12 kb RAM size. Additionally, it is composed of 8 ADC channels. It comprises 8 timers. Moreover, the data bus width includes 16bit. The instruction set has cisc architecture. It is a flash program memory type. The package is a sort of lfqfp. It features 20mhz of maximum frequency. It has a maximum operating temperature of +85 °c. The product belongs to a family upd. On the other hand, the 78k0r is the device core. The ADC has 10bit resolution. The timer has 16bit resolution. Timers options include 8 x 16 bit. It contains 80 pins. The product carries 1(7 channel) of pulse width modulation. The product is available in surface mount configuration. It includes 7 PWM channels . Its accurate length is 12mm. In addition, the height is 1.4mm. It has 1.8 → 5.5 v of typical operating supply voltage. The ADCs included 8 x 10 bit. Whereas, the minimum operating temperature of the product is -40 °c.
For more information please check the datasheets.
