Analog Devices AD8293G80BRJZ-R2, Instrumentation Amplifier, 30μV Offset 500Hz, R-RO, 1.8 → 5.5 V, 8-Pin SOT-23

AD8293G80BRJZ-R2 Analog Devices , Instrumentation Amplifier, 30μV Offset 500Hz, R-RO, 1.8 → 5.5 V, 8-Pin SOT-23
AD8293G80BRJZ-R2
AD8293G80BRJZ-R2
ET14102235
ET14102235
Instrumentation Amplifiers
Instrumentation Amplifiers
Analog Devices

Product Information

Minimum CMRR:
110dB
Maximum Input Offset Voltage:
30µV
Typical Gain Bandwidth Product:
500Hz
Dimensions:
2.9 x 1.6 x 1.3mm
Mounting Type:
Surface Mount
Maximum Input Resistance:
10GΩ
Power Supply Type:
Single
Rail to Rail:
Rail to Rail Output
Height:
1.3mm
Typical Single Supply Voltage:
1.8 → 5.5 V
Width:
1.6mm
Length:
2.9mm
Package Type:
SOT-23
Minimum Operating Temperature:
-40 °C
Maximum Supply Current:
2 nA
Maximum Operating Temperature:
+85 °C
Pin Count:
8
RoHs Compliant
Checking for live stock

This is Instrumentation Amplifier 30μV Offset 500Hz R-RO 1.8 → 5.5 V 8-Pin SOT-23 manufactured by Analog Devices. The manufacturer part number is AD8293G80BRJZ-R2. It is designed with a minimum 110db CMRR . It has a maximum 30µv input offset voltage . Features 500hz typical gain bandwidth. The given dimensions of the product include 2.9 x 1.6 x 1.3mm. The product is available in surface mount configuration. It has a maximum 10gω input resistance . It is a type of single power supply. Rail to rail options include rail to rail output. In addition, the height is 1.3mm. It has a typical single supply voltage of 1.8 → 5.5 v. Furthermore, the product is 1.6mm wide. Its accurate length is 2.9mm. The package is a sort of sot-23. Whereas, the minimum operating temperature of the product is -40 °c. Moreover, it has a maximum 2 na supply current . It has a maximum operating temperature of +85 °c. It contains 8 pins.
