Hazardous Area Certification:
No
Conductor Type:
Stranded
Minimum Operating Temperature:
-55°C
Conductor Material:
Copper
Series:
HELUTHERM
Fire Behaviour:
IEC 60332-3-22, DIN EN 60332-1-2, Toxic Gases, No Release of Corrosive, No fire propagation, IEC 60332-1-2, Flame retardant according to DIN VDE 0482-332-1-2, Din En 60332-3-22, Bundle Fire Test Acc. to Din Vde 0482-332-3-22
Screened/Unscreened:
Screened
Jacket Colour:
Black
American Wire Gauge:
14AWG
Jacket Material:
Cross Linked Polyolefin
Number of Cores:
1
Cable CSA:
2.5 mm²
Product Type:
Control Cable
Maximum Operating Temperature:
145°C
Standards/Approvals:
DIN VDE 0473-811-404, DIN VDE 0482-1034-1+2, DIN VDE 0482-332-1-2, DIN VDE 0482-332-3-22, DIN VDE 0482-754-1, DIN VDE 0482-754-2, DNV, EAC, IEC 60228, IEC 60332-1-2, IEC 60332-3-22, IEC 60754-1, IEC 60754-2, IEC 60811-404, IEC 61034-1+2, DIN EN 60332-1-2, DIN EN 60332-3-22, DIN EN 60754-1, DIN EN 60754-2, DIN EN 60811-404, DIN EN 61034-1+2, DIN EN ISO 4892-2, DIN VDE 0293-308, DIN VDE 0295
