NCS2220AMUT1G ON Semiconductor, Dual Comparator, Rail to Rail O/P, 0.85 → 6 V 8-Pin UDFN

NCS2220AMUT1G ON Semiconductor, Dual Comparator, Rail to Rail O/P, 0.85 → 6 V 8-Pin UDFN
NCS2220AMUT1G
NCS2220AMUT1G ON Semiconductor, Dual Comparator, Rail to Rail O/P, 0.85 → 6 V 8-Pin UDFN
onsemi

Product Information

Automotive Standard:
No
Comparator Type:
Low Power
Maximum Operating Temperature:
105?C
Minimum Supply Voltage:
0.85V
Maximum Supply Voltage:
6V
Series:
NCS2220A
Output Type:
Rail to Rail
Height:
0.5mm
Typical Response Time:
0.5?s
Length:
1.6mm
Package Type:
UDFN
Minimum Operating Temperature:
-40?C
Standards/Approvals:
No
Number of Channels:
2
Product Type:
Comparator
Supply Current:
17?A
Pin Count:
8
Mount Type:
Surface
HTSUS:
8542.39.0001
RoHS Status:
ROHS3 Compliant
Current - Input Bias (Max):
1pA @ 6V
Current - Quiescent (Max):
17µA
Operating Temperature:
-40°C ~ 105°C
Voltage - Supply, Single/Dual (±):
0.85V ~ 6V
Package / Case:
8-UFDFN Exposed Pad
Type:
General Purpose
Propagation Delay (Max):
500ns
REACH Status:
REACH Unaffected
Output Type:
Complementary, Rail-to-Rail
Hysteresis:
20mV
edacadModel:
NCS2220AMUT1G Models
edacadModelUrl:
/en/models/1792662
CMRR, PSRR (Typ):
53dB CMRR, 45dB PSRR
Package:
Tape & Reel (TR)
Voltage - Input Offset (Max):
5mV @ 6V
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - Output (Typ):
-
standardLeadTime:
7 Weeks
Mounting Type:
Surface Mount
Series:
-
Supplier Device Package:
8-UDFN (1.6x1.6)
Number of Elements:
2
Base Product Number:
NCS2220
ECCN:
EAR99
RoHs Compliant
warehouse-1
1928 - In Stock

Ships in 5-7 business days

Quantity
Unit Price (ex VAT)
Price
5
£ 0.50
£ 2.50
10
£ 0.42
£ 4.20
100
£ 0.29
£ 29.00
Mfr Part No:
NCS2220AMUT1G
Seller:
onsemi (warehouse-1)
Origin:
Warranty:
Manufacturer
Data Code:
ET21469006
Order Today!
From: United Kingdom
Est Ship Date: 05 Jun, 2026
Est Fastest Delivery: 09 Jun, 2026

This is ON Semiconductor Dual Comparator Rail to Rail O/P 0.85 → 6 V 8-Pin UDFN manufactured by onsemi. The manufacturer part number is NCS2220AMUT1G. The product complies with automotive standard - no. It has an adorable low power type comparator . It has a maximum operating temperature of 105?c. It has a minimum 0.85v supply voltage . The product requires a maximum 6v supply voltage . The product ncs2220a, is a highly preferred choice for users. Furthermore, it has arail to rail output. In addition, the height is 0.5mm. It has a typical 0.5?s response time . Its accurate length is 1.6mm. The package is a sort of udfn. Whereas, the minimum operating temperature of the product is -40?c. It is supplied with 2 channels. comparator is a versatile product designed to provide user-defined applications. It features 17?a supply current. It contains 8 pins. It has a surface type mount . It is assigned with possible HTSUS value of 8542.39.0001. The product is rohs3 compliant. The maximum input bias current includes 1pa @ 6v. It has a maximum quiescent current of 17µa. The product has -40°c ~ 105°c operating temperature range. It features a typical 0.85v ~ 6v voltage of single or dual. Moreover, the product comes in 8-ufdfn exposed pad. It comes in general purpose configuration. Has a maximum 500ns propagation delay. In addition, it is reach unaffected. Furthermore, it has acomplementary, rail-to-rail output. Features 20mv hysteresis. Typical CMRR, PSRR of 53db cmrr, 45db psrr. It is shipped in tape & reel (tr) package . The maximum input offset voltage of 5mv @ 6v. Its typical moisture sensitivity level is 1 (unlimited). It has a long 7 weeks standard lead time. The product is available in surface mount configuration. 8-udfn (1.6x1.6) is the supplier device package value. It carries 2 elements. Moreover, it corresponds to ncs2220, a base product number of the product. The product is designated with the ear99 code number.

pdf icon
Datasheet(Technical Reference)
pdf icon
ESD Control Selection Guide V1(Technical Reference)
pdf icon
onsemi RoHS(Environmental Information)
pdf icon
Wafer Fab Change 14/Nov/2023(PCN Assembly/Origin)
pdf icon
NCS2220A(Datasheets)
pdf icon
Covering Tape/Material Chg 20/May/2016(PCN Packaging)
