Housing Material:
Polyamide
Termination Type:
Screw
Series:
SACC-M12FRS-3PECON-PG 9-M
Minimum Operating Temperature:
-40°C
Pole Format:
4
Current:
12A
Cable Diameter:
8mm
Standards/Approvals:
IEC 61076-2-111, UL Recognised, cUL Recognised
Voltage:
630 V ac
Contact Plating:
Gold
Contact Material:
Copper Zinc Alloy
Product Type:
Power Connector
Connector Gender:
Female
Maximum Operating Temperature:
85°C
Mount Type:
Screw
HTSUS:
8536.69.4020
RoHS Status:
ROHS3 Compliant
Mounting Feature:
-
Operating Temperature:
-40°C ~ 85°C
Shell Size, MIL:
-
Number of Positions:
4
Contact Finish - Mating:
Gold
Backshell Material, Plating:
-
Shielding:
Shielded
Cable Opening:
0.236" ~ 0.315" (6.00mm ~ 8.00mm)
title:
1107272
Shell Material:
Zinc Die Cast
REACH Status:
REACH Affected
Current Rating (Amps):
12A
Applications:
-
Primary Material:
Metal
Material Flammability Rating:
UL94 V-0
Voltage Rating:
630VAC
Shell Size - Insert:
M12-4
Connector Type:
Plug, Female Sockets
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Threaded
Termination:
Screw
standardLeadTime:
4 Weeks
Insert Material:
Polyamide (PA), Nylon
Orientation:
S
Ingress Protection:
IP67 - Dust Tight, Waterproof
Features:
Backshell
Mounting Type:
Free Hanging (In-Line), Right Angle
Shell Finish:
Nickel
Color:
Silver
Series:
SACC
Packaging:
Bulk
Contact Finish Thickness - Mating:
-
Contact Material:
Copper Alloy
ECCN:
EAR99
