Number of Contacts:
3
Current Rating:
7.0A
Mating Type:
Bayonet
Mounting Type:
Cable Mount
IP Rating:
IP68, IP69K
Series:
UTS
Body Orientation:
Straight
Voltage Rating:
600.0 V
Contact Gender:
Male
Termination Method:
Solder
Housing Material:
Thermoplastic
Plug/Socket:
Socket
Contact Plating:
Gold
Shell Size:
8
Strain Relief:
Yes
Maximum Operating Temperature:
+105°C
Minimum Operating Temperature:
-40°C
Contact Material:
Copper
HTSUS:
8536.69.4020
RoHS Status:
ROHS3 Compliant
Mounting Feature:
-
Operating Temperature:
-40°C ~ 105°C
Shell Size, MIL:
-
Number of Positions:
3
Backshell Material, Plating:
Polyamide (PA), Nylon
Shielding:
Unshielded
Cable Opening:
-
Shell Material:
Polyamide (PA), Nylon
REACH Status:
REACH Unaffected
Current Rating (Amps):
7A
edacadModel:
UTS6JC8E3P Models
Applications:
Energy, Instrumentation, Lighting, Telecommunications
Contact Finish - Mating:
Gold
Primary Material:
Plastic
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/3974202
Voltage Rating:
250V
Shell Size - Insert:
8-3
Connector Type:
Plug, Male Pins
Moisture Sensitivity Level (MSL):
Not Applicable
Fastening Type:
Bayonet Lock
Termination:
Solder Cup
standardLeadTime:
12 Weeks
Insert Material:
Polychloroprene
Orientation:
N (Normal)
Ingress Protection:
IP68/IP69K - Dust Tight, Water Resistant, Waterproof
Features:
Backshell, Coupling Nut, UV Resistant
Mounting Type:
Free Hanging (In-Line)
Shell Finish:
-
Color:
Black
Series:
Trim Trio® UTS Hi Seal
Packaging:
Bulk
Contact Finish Thickness - Mating:
16.0µin (0.41µm)
Contact Material:
Brass
Base Product Number:
UTS6J
ECCN:
EAR99
