Mount Type:
Plug-in
Housing Material:
Copper Zinc Alloy
Shell Size:
M16
Plug/Socket:
Socket
Contact Plating:
Gold
Product Type:
Circular Connector
Maximum Operating Temperature:
85°C
Minimum Operating Temperature:
-25°C
IP Rating:
IP65, IP67
Contact Gender:
Female
Standards/Approvals:
cULus Recognised, IEC 61076-2-010
Connector Size:
M12
Orientation:
Straight
Current:
4A
Mating Type:
Push Pull
Series:
SACC
Coding:
A
Voltage:
60 V
Termination Type:
Solder
Number of Contacts:
5
Contact Material:
Copper Zinc Alloy
HTSUS:
8536.69.4020
RoHS Status:
ROHS3 Compliant
Mounting Feature:
Bulkhead - Front Side Nut
Operating Temperature:
-25°C ~ 85°C
Shell Size, MIL:
-
Number of Positions:
5
Contact Finish - Mating:
Gold
Backshell Material, Plating:
-
Shielding:
Unshielded
Cable Opening:
-
Shell Material:
Brass
REACH Status:
REACH Affected
Current Rating (Amps):
4A
Applications:
-
Primary Material:
Metal
Material Flammability Rating:
UL94 V-0
Voltage Rating:
60V
Shell Size - Insert:
M12-5
Connector Type:
Receptacle, Female Sockets
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Push-Pull
Termination:
Solder
standardLeadTime:
10 Weeks
Insert Material:
Polyamide (PA66), Nylon 6/6
Orientation:
A
Ingress Protection:
IP67 - Dust Tight, Waterproof
Features:
-
Mounting Type:
Panel Mount
Shell Finish:
Nickel
Color:
Silver
Series:
SACC
Packaging:
Bulk
Contact Finish Thickness - Mating:
-
Contact Material:
Copper Zinc
ECCN:
EAR99
