Bulgin PXP7012/03P/ST

PXP7012-03P-ST Bulgin PXP7012/03P/ST
PXP7012/03P/ST
PXP7012/03P/ST
ET10975405
Bulgin

Product Information

Number of Contacts:
3
Current Rating:
25.0A
Mating Type:
Quick Connect
Mounting Type:
Front Mount
IP Rating:
IP66, IP68, IP69K
Series:
Buccaneer 7000
Body Orientation:
Straight
Voltage Rating:
600.0 V
Contact Gender:
Male
Termination Method:
Screw
Housing Material:
Polymer
Plug/Socket:
Plug
Contact Plating:
Nickel
Shell Size:
46
Strain Relief:
No
Maximum Operating Temperature:
+120°C
Minimum Operating Temperature:
-40°C
Contact Material:
Brass
HTSUS:
8536.69.4020
RoHS Status:
ROHS3 Compliant
Mounting Feature:
Bulkhead - Rear Side Nut
Operating Temperature:
-40°C ~ 120°C
Shell Size, MIL:
-
Number of Positions:
3 (2 Power + PE)
Backshell Material, Plating:
-
Shielding:
Unshielded
Cable Opening:
-
Shell Material:
Polycarbonate/Polybutylene Terephthalate (PBT), Halogen Free
REACH Status:
REACH Unaffected
Current Rating (Amps):
25A
edacadModel:
PXP7012/03P/ST Models
Applications:
-
Contact Finish - Mating:
Nickel
Primary Material:
Plastic
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/4496741
Voltage Rating:
600V
Shell Size - Insert:
-
Connector Type:
Receptacle, Male Pins
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Bayonet Lock
Termination:
Screw
standardLeadTime:
22 Weeks
Insert Material:
-
Orientation:
Keyed
Ingress Protection:
IP66/IP68/IP69K - Dust Tight, Water Resistant, Waterproof
Features:
-
Mounting Type:
Panel Mount
Shell Finish:
-
Color:
Gray
Series:
Buccaneer® 7000
Packaging:
Bulk
Contact Finish Thickness - Mating:
-
Contact Material:
Brass
Base Product Number:
PXP7012
ECCN:
EAR99
RoHs Compliant
Checking for live stock

This is manufactured by Bulgin. The manufacturer part number is PXP7012/03P/ST. The product contains 3 contacts. The product has a current rating of 25.0a. It is a type of quick connect mating. The product is available in front mount configuration. It is IP rated with ip66, ip68, ip69k. The product buccaneer 7000, is a highly preferred choice for users. It has straight body orientation. Moreover, the product has a nominal 600.0 v voltage rating. This male contact is widely suited for specific applications. It allows screw termination method. The product also features robust polymer housing material. It comprises a plug. The high-quality nickel is used as contact plating material. The shell has 46 size. It has a strain relief characteristic no . It has a maximum operating temperature of +120°c. Whereas, the minimum operating temperature of the product is -40°c. The product is made from sturdy brass materials. It is assigned with possible HTSUS value of 8536.69.4020. The product is rohs3 compliant. The product's mounting feature includes bulkhead - rear side nut. The product has -40°c ~ 120°c operating temperature range. The product carries possible position value of 3 (2 power + pe). Furthermore, the product is shielded with unshielded. It is made from highly reliable polycarbonate/polybutylene terephthalate (pbt), halogen free materials. In addition, it is reach unaffected. Additionally, the product's output is 25a. It has nice contact finishing of nickel. The basic product material is plastic. It carries ul94 v-0 of material flammability rating. Moreover, the product has a nominal 600v voltage rating. receptacle, male pins Connector type offer robust functionality. Its typical moisture sensitivity level is 1 (unlimited). Furthermore, bayonet lock is the Fastening Type of the product. The product features screw termination style. It has a long 22 weeks standard lead time. The product has a keyed orientation. It is IP rated with ip66/ip68/ip69k - dust tight, water resistant, waterproof. The product is available in panel mount configuration. It has a classic gray colour. The product buccaneer® 7000, is a highly preferred choice for users. In addition, bulk is the available packaging type of the product. Moreover, it corresponds to pxp7012, a base product number of the product. The product is designated with the ear99 code number.
