American Wire Gauge:
24 AWG
Current Rating:
4 A
Conductor Resistance:
5 mΩ
Oil Resistant:
Yes
Number of Cores:
4
Connector 2 Housing Gender:
Male
Outer Diameter:
3.95mm
Shielding:
Unshielded
Standards Met:
UL
Cable Shape:
4 Twisted Pair
Voltage Rating:
300 V
Core Strands:
4 x 0.25 mm²
Shielded/Unshielded:
Unshielded
Operating Temperature Range:
-40 → +80 °C
Maximum Operating Temperature:
+80°C
IP Rating:
IP65, IP67, IP68
Connector 1 Orientation:
Straight
Minimum Bend Radius:
20 mm
Connector 1 Gender:
Male
Length:
3m
Sheath Material:
PUR
Connector 2 Orientation:
Straight
Connector 2 Gender:
Female
Connector 2 Number of Contacts:
4
Conductor Material:
CuSn
Series:
SAC-4P-M 8MS/3.0-PUR/M 8FS
Size of Strands:
32 x 0.10 mm
Connector 1 Number of Contacts:
4
Coding:
A
Sheath Colour:
Black
Cross Sectional Area:
0.25 mm²
Minimum Operating Temperature:
-40°C
Connector 2:
M8
Connector 1:
M8
Connector 1 Housing Gender:
Female
Insulation Material:
PP
1st Connector Orientation:
-
2nd Connector Mounting Type:
Free Hanging (In-Line)
HTSUS:
8544.42.9090
RoHS Status:
ROHS3 Compliant
Usage:
Industrial Environments
Shielding:
Unshielded
1st Connector Number of Positions Loaded:
All
1st Connector Shell Size - Insert:
M8
REACH Status:
REACH Affected
Cable Material:
Polyurethane (PUR)
2nd Connector Type:
Plug
Assembly Configuration:
Standard
2nd Connector Number of Positions:
4
2nd Connector Number of Positions Loaded:
All
Manufacturer:
Phoenix Contact
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
9.84' (3.00m)
1st Connector Gender:
Male Pins
standardLeadTime:
8 Weeks
1st Connector Type:
Receptacle
2nd Connector Shell Size - Insert:
M8
1st Connector Number of Positions:
4
Ingress Protection:
IP65/IP67/IP68 - Dust Tight, Water Resistant, Waterproof
Color:
Black
Series:
-
2nd Connector Orientation:
-
Cable Type:
Round
Packaging:
Bulk
2nd Connector Gender:
Female Sockets
1st Connector Mounting Type:
Free Hanging (In-Line)
ECCN:
EAR99
