American Wire Gauge:
24 AWG
Current Rating:
4 A
Conductor Resistance:
78 O/km
Oil Resistant:
Yes
Number of Cores:
3
Connector 2 Housing Gender:
Male
Outer Diameter:
3.6mm
Standards Met:
cUL, cULus, EAC, IEC 61076-2-104, UL
Cable Shape:
Twisted Pair
Voltage Rating:
48 V
Shielded/Unshielded:
Unshielded
Maximum Operating Temperature:
+80°C
IP Rating:
IP65, IP67, IP68
Connector 1 Orientation:
Straight
Minimum Bend Radius:
18 (Fixed) mm, 36 (Movable) mm
Fire Behaviour:
Halogen Free
Connector 1 Gender:
Female
Length:
600mm
Sheath Material:
PUR
Connector 2 Orientation:
Straight
Connector 2 Gender:
Male
Connector 2 Number of Contacts:
3
Conductor Material:
Copper
Series:
SAC-3P-M 8MS/0.6-PUR/M 8FS
Connector 1 Housing Gender:
Female
Connector 1 Number of Contacts:
3
Coding:
A
Sheath Colour:
Black
Cross Sectional Area:
0.25 mm²
Minimum Operating Temperature:
-5 (Flexible) °C, -40 (Fixed) °C
Connector 2:
M8
Connector 1:
M8
Insulation Material:
PUR
1st Connector Orientation:
-
2nd Connector Mounting Type:
Free Hanging (In-Line)
HTSUS:
8544.42.9090
RoHS Status:
ROHS3 Compliant
Cable Material:
Polyurethane (PUR)
Usage:
Industrial Environments
Shielding:
Unshielded
1st Connector Number of Positions Loaded:
All
1st Connector Shell Size - Insert:
M8
REACH Status:
REACH Affected
2nd Connector Type:
Plug
Assembly Configuration:
Standard
2nd Connector Number of Positions:
3
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
1.97' (600.00mm)
1st Connector Gender:
Male Pins
standardLeadTime:
8 Weeks
1st Connector Type:
Receptacle
2nd Connector Shell Size - Insert:
M8
1st Connector Number of Positions:
3
Ingress Protection:
IP65/IP67/IP68 - Dust Tight, Water Resistant, Waterproof
Color:
Black
Series:
-
2nd Connector Orientation:
-
Cable Type:
Round
2nd Connector Number of Positions Loaded:
All
2nd Connector Gender:
Female Sockets
1st Connector Mounting Type:
Free Hanging (In-Line)
ECCN:
EAR99
