American Wire Gauge:
26 AWG
Current Rating:
1.5 A
Conductor Resistance:
139 O/km
Oil Resistant:
Yes
Number of Cores:
8
Outer Diameter:
5.1mm
Standards Met:
IEC 61076-2-104
Cable Shape:
Twisted Pair
Voltage Rating:
30 V ac/dc
Shielded/Unshielded:
Unshielded
Operating Temperature Range:
-25 → +80 °C, -40 → +80 °C
Maximum Operating Temperature:
+80°C
IP Rating:
IP65, IP67, IP68
Connector 1 Orientation:
Right Angle
Minimum Bend Radius:
25.5 mm, 51 mm
Connector 1 Gender:
Female
Length:
5m
Sheath Material:
Polyurethane PUR
Conductor Material:
Bare Cu litz wires
Series:
0-PUR/M 8FR, SAC-8P- 5
Connector 1 Housing Gender:
Female
Connector 1 Number of Contacts:
8
Coding:
A
Sheath Colour:
Black, Grey
Cross Sectional Area:
0.14 mm²
Minimum Operating Temperature:
-25 °C, -40 °C
Connector 2:
Unterminated
Connector 1:
M8
Insulation Material:
PP
1st Connector Orientation:
A
2nd Connector Mounting Type:
-
HTSUS:
8544.42.9090
RoHS Status:
ROHS3 Compliant
Usage:
Industrial Environments
Shielding:
Unshielded
1st Connector Number of Positions Loaded:
All
1st Connector Shell Size - Insert:
M8
REACH Status:
REACH Unaffected
Cable Material:
Polyurethane (PUR)
2nd Connector Type:
Wire Leads
Assembly Configuration:
Standard
2nd Connector Number of Positions:
-
2nd Connector Number of Positions Loaded:
-
Manufacturer:
Phoenix Contact
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
16.40' (5.00m)
1st Connector Gender:
Female Sockets
standardLeadTime:
8 Weeks
1st Connector Type:
Plug, Right Angle
2nd Connector Shell Size - Insert:
-
1st Connector Number of Positions:
8
Ingress Protection:
IP65/IP67/IP68 - Dust Tight, Water Resistant, Waterproof
Color:
Black
Series:
-
2nd Connector Orientation:
-
Cable Type:
Round
Packaging:
Bulk
2nd Connector Gender:
-
1st Connector Mounting Type:
Free Hanging (In-Line)
ECCN:
EAR99
