Standard Zener Diodes

STZ6-8TT146 Standard Zener Diodes
ROHM

Product Information

Nominal Zener Voltage:
7.14V
Dimensions:
2.9 x 1.6 x 1.1mm
Mounting Type:
Surface Mount
Power Dissipation:
200mW
Maximum Operating Temperature:
150 °C
Maximum Reverse Leakage Current:
500nA
Maximum Zener Impedance:
60Ω
Height:
1.1mm
Width:
1.6mm
Length:
2.9mm
Zener Type:
Voltage Regulator
Number of Elements per Chip:
2
Maximum Power Dissipation:
200 mW
Package Type:
SOT-346
Diode Configuration:
Common Anode
Pin Count:
3
Test Current:
5mA
RoHs Compliant
Checking for live stock

This is Standard Zener Diodes manufactured by ROHM. The manufacturer part number is STZ6.8TT146. Its nominal Zener voltage is 7.14v. The given dimensions of the product include 2.9 x 1.6 x 1.1mm. The product is available in surface mount configuration. It has about 200mw power dissipation . It has a maximum operating temperature of 150 °c. The product has a maximum 500na of reverse leakage current. While it has 60ω of maximum Zener impedance. In addition, the height is 1.1mm. Furthermore, the product is 1.6mm wide. Its accurate length is 2.9mm. The Zener is a type of voltage regulator Zener with unique features. It consists of 2 elements per chip. Provides up to 200 mw maximum power dissipation. The package is a sort of sot-346. The diode features a common anode configuration. It contains 3 pins. In addition, it has 5ma test current.

pdf icon
Datasheet STZ6.8TT146(Technical Reference)
