Vishay Zener Diode, 20V 5% 3 W SMT 2-Pin DO-214AA

SMBZ5932B-E3-52 Vishay Zener Diode, 20V 5% 3 W SMT 2-Pin DO-214AA
SMBZ5932B-E3/52
Vishay

Product Information

Nominal Zener Voltage:
20V
Dimensions:
4.57 x 3.94 x 2.24mm
Mounting Type:
Surface Mount
Maximum Zener Impedance:
14Ω
Maximum Operating Temperature:
+150 °C
Maximum Reverse Leakage Current:
1µA
Maximum Power Dissipation:
3 W
Package Type:
DO-214AA (SMB)
Number of Elements per Chip:
1
Minimum Operating Temperature:
-65 °C
Zener Type:
Voltage Regulator
Zener Voltage Tolerance:
5%
Diode Configuration:
Single
Pin Count:
2
Test Current:
18.7mA
RoHs Compliant
Checking for live stock

This is Zener Diode 20V 5% 3 W SMT 2-Pin DO-214AA manufactured by Vishay. The manufacturer part number is SMBZ5932B-E3/52. Its nominal Zener voltage is 20v. The given dimensions of the product include 4.57 x 3.94 x 2.24mm. The product is available in surface mount configuration. While it has 14ω of maximum Zener impedance. It has a maximum operating temperature of +150 °c. The product has a maximum 1µa of reverse leakage current. Provides up to 3 w maximum power dissipation. The package is a sort of do-214aa (smb). It consists of 1 elements per chip. Whereas, the minimum operating temperature of the product is -65 °c. The Zener is a type of voltage regulator Zener with unique features. It has 5% Zener voltage tolerance. The diode features a single configuration. It contains 2 pins. In addition, it has 18.7ma test current.

pdf icon
SMBZ5919B thru SMBZ5945B, Surface Mount Power Voltage-Regulating Diodes(Technical Reference)
pdf icon
ESD Control Selection Guide V1(Technical Reference)

Reviews

  • Be the first to review.

FAQs

Yes. You can also search SMBZ5932B-E3/52 on website for other similar products.
We accept all major payment methods for all products including ET13884511. Please check your shopping cart at the time of order.
You can order Vishay brand products with SMBZ5932B-E3/52 directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Zener Diodes category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Vishay Zener Diode, 20V 5% 3 W SMT 2-Pin DO-214AA. You can also check on our website or by contacting our customer support team for further order details on Vishay Zener Diode, 20V 5% 3 W SMT 2-Pin DO-214AA.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET13884511 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Vishay" products on our website by using Enrgtech's Unique Manufacturing Part Number ET13884511.
Yes. We ship SMBZ5932B-E3/52 Internationally to many countries around the world.
