TDK CLF12555 Series Type 12555 Shielded Wire-wound SMD Inductor with a Ferrite Core, 68 μH ±20% Wire-Wound 2.6A Idc

CLF12555T-680M TDK CLF12555 Series Type 12555 Shielded Wire-wound SMD Inductor with a Ferrite Core, 68 μH ±20% Wire-Wound 2.6A Idc
TDK

Product Information

Maximum DC Resistance:
150mΩ
Inductor Construction:
Wire-Wound
Dimensions:
12.5 x 12.1 x 5.5mm
Shielded:
Yes
Series:
CLF12555
Length:
12.5mm
Height:
5.5mm
Maximum DC Current:
2.6A
Depth:
12.1mm
Core Material:
Ferrite
Inductance:
68 μH
Maximum Self Resonant Frequency:
0.1MHz
Maximum Operating Temperature:
+105°C
Tolerance:
±20%
Minimum Operating Temperature:
-40°C
Package/Case:
12555
RoHs Compliant
Checking for live stock

This is CLF12555 Series Type 12555 Shielded Wire-wound SMD Inductor with a Ferrite Core 68 μH ±20% Wire-Wound 2.6A Idc manufactured by TDK. The manufacturer part number is CLF12555T-680M. It allows up to 150mω maximum DC resistance. The inductor is designed as wire-wound inductor. The given dimensions of the product include 12.5 x 12.1 x 5.5mm. Shielding Options yes. The product clf12555, is a highly preferred choice for users. Its accurate length is 12.5mm. In addition, the height is 5.5mm. While it carries 2.6a of maximum DC current. The product comes in 12.1mm depth. The core is manufactured from highly durable and reliable ferrite materials. The product has a 68 μh inductance value. It provides 0.1mhz of maximum self-resonant frequency. It has a maximum operating temperature of +105°c. It features ±20% of tolerance value. Whereas, the minimum operating temperature of the product is -40°c. Concerning its package and casing, it is 12555.
