Wurth WE-PD Series Shielded Wire-wound SMD Inductor 7.6 μH -20 %, 40 % 7.4A Idc

Enrgtech Part No: ET13961956
|
Manufacturer Part No:
74477007
|
Manufacturer: Wurth Elektronik

74477007 Wurth WE-PD Series Shielded Wire-wound SMD Inductor 7.6 μH -20 %, 40 % 7.4A Idc

Product Information

Maximum DC Resistance:

20mΩ

Dimensions:

12 x 12 x 8mm

Shielded:

Yes

Series:

WE-PD

Length:

12mm

Height:

8mm

Maximum DC Current:

7.4A

Depth:

12mm

Inductance:

7.6 μH

Maximum Self Resonant Frequency:

21.3MHz

Maximum Operating Temperature:

+125°C

Tolerance:

-20 %, 40 %

Checking for live stock

This is Wurth WE-PD Series Shielded Wire-wound SMD Inductor 7.6 μH -20 % 40 % 7.4A Idc manufactured by Wurth Elektronik. The manufacturer part number is 74477007. It allows up to 20mω maximum DC resistance. The given dimensions of the product include 12 x 12 x 8mm. Shielding Options yes. The product we-pd, is a highly preferred choice for users. Its accurate length is 12mm. In addition, the height is 8mm. While it carries 7.4a of maximum DC current. The product comes in 12mm depth. The product has a 7.6 μh inductance value. It provides 21.3mhz of maximum self-resonant frequency. It has a maximum operating temperature of +125°c. It features -20 %, 40 % of tolerance value. Whereas, the minimum operating temperature of the product is -40°c.

8 Design Tips for Power Inductors from Wurth Elektronik - Application Note(Technical Reference)

High Power Wireless Power Transfer for the Industrial Environment - ANP032D Application Note(Technical Reference)

74477007 Data Sheet(Technical Reference)
