Wurth WE-MAPI Series Type 4020 Shielded Wire-wound SMD Inductor with a Magnetic Iron Alloy Core, 560 nH Moulded 8.5A Idc

744383560056 Wurth WE-MAPI Series Type 4020 Shielded Wire-wound SMD Inductor with a Magnetic Iron Alloy Core, 560 nH Moulded 8.5A Idc
744383560056
744383560056
Wurth Elektronik

Product Information

Maximum DC Resistance:
8.4mΩ
Inductor Construction:
Moulded
Dimensions:
4.1 x 4.1 x 2.1mm
Shielded:
Yes
Series:
WE-MAPI
Minimum Operating Temperature:
-40°C
Length:
4.1mm
Height:
2.1mm
Maximum DC Current:
8.5A
Depth:
4.1mm
Core Material:
Magnetic Iron Alloy
Inductance:
560 nH
Maximum Self Resonant Frequency:
85MHz
Maximum Operating Temperature:
+125°C
Moulded:
Yes
Package/Case:
4020
RoHs Compliant
Checking for live stock

This is Wurth WE-MAPI Series Type 4020 Shielded Wire-wound SMD Inductor with a Magnetic Iron Alloy Core 560 nH Moulded 8.5A Idc manufactured by Wurth Elektronik. The manufacturer part number is 744383560056. It allows up to 8.4mω maximum DC resistance. The inductor is designed as moulded inductor. The given dimensions of the product include 4.1 x 4.1 x 2.1mm. Shielding Options yes. The product we-mapi, is a highly preferred choice for users. Whereas, the minimum operating temperature of the product is -40°c. Its accurate length is 4.1mm. In addition, the height is 2.1mm. While it carries 8.5a of maximum DC current. The product comes in 4.1mm depth. The core is manufactured from highly durable and reliable magnetic iron alloy materials. The product has a 560 nh inductance value. It provides 85mhz of maximum self-resonant frequency. It has a maximum operating temperature of +125°c. In addition, it is moulded yes . Concerning its package and casing, it is 4020.
