Souriau, SMS Male Connector Housing, 24 Way, 6 Row

SMS24PDH3 Souriau, SMS Male Connector Housing, 24 Way, 6 Row
SMS24PDH3
Souriau Sunbank by Eaton

Product Information

Mounting Type:
Cable Mount
Series:
SMS
Body Orientation:
Straight
Housing Material:
Polyamide
Width:
65.1mm
Length:
90.4mm
Number of Rows:
6
Gender:
Male
For Use With:
Quick Mating PCB Connector
Number of Contacts:
24
HTSUS:
8536.69.8000
RoHS Status:
ROHS3 Compliant
Note:
Contacts Not Included
Operating Temperature:
-40°C ~ 105°C
Number of Positions:
24
REACH Status:
REACH Unaffected
edacadModel:
SMS24PDH3 Models
Number of Rows:
4
edacadModelUrl:
/en/models/4492923
Connector Type:
Plug
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Latch Lock
Features:
Strain Relief
Mounting Type:
Free Hanging (In-Line)
Color:
White
Series:
SMS
Packaging:
-
Insulation Material:
Polyamide (PA66), Nylon 6/6
Pitch:
0.200" (5.08mm)
Contact Type:
Male or Female
Row Spacing:
0.200" (5.08mm)
Contact Termination:
Crimp
Base Product Number:
SMS24P
ECCN:
EAR99
RoHs Compliant
Checking for live stock

This is Souriau SMS Male Connector Housing 24 Way 6 Row manufactured by Souriau Sunbank by Eaton. The manufacturer part number is SMS24PDH3. The product is available in cable mount configuration. The product sms, is a highly preferred choice for users. It has straight body orientation. The product also features robust polyamide housing material. Furthermore, the product is 65.1mm wide. Its accurate length is 90.4mm. It comes in 6 of rows. In addition, male is the available "Gender" of the product. The product is highly suitable for quick mating pcb connector. The product contains 24 contacts. It is assigned with possible HTSUS value of 8536.69.8000. The product is rohs3 compliant. Note: contacts not included. The product has -40°c ~ 105°c operating temperature range. The product carries possible position value of 24. In addition, it is reach unaffected. It comes in 4 of rows. plug Connector type offer robust functionality. Its typical moisture sensitivity level is 1 (unlimited). Furthermore, latch lock is the Fastening Type of the product. The splendid features of the product include strain relief. The product is available in free hanging (in-line) configuration. It has a classic white colour. It has a robust polyamide (pa66), nylon 6/6 insulation material. Moreover, the product is 0.200" (5.08mm). It has typical contact type of male or female. The space between it rows includes 0.200" (5.08mm). It also incorporates crimp contact terminals. Moreover, it corresponds to sms24p, a base product number of the product. The product is designated with the ear99 code number.

pdf icon
Catalogue(Technical Reference)
pdf icon
SMS Quick Mating Panel & Cable Connectors(Technical Reference)
pdf icon
SMS Flame Retardant Quick Mating Cable Plug Housing with Hood(Technical Reference)
pdf icon
SMS4PDH3 Drawing(Product Drawings)
