Linear Technology LT1461DHS8-2.5#PBF, Fixed Series Voltage Reference 2.5V, ±0.15 % 8-Pin, SOIC

LT1461DHS8-2-5-PBF Linear Technology LT1461DHS8-2.5#PBF, Fixed Series Voltage Reference 2.5V, ±0.15 % 8-Pin, SOIC
LT1461DHS8-2.5#PBF
Analog Devices

Product Information

Load Regulation:
50 ppm/mA
Dimensions:
5.004 x 3.988 x 1.498mm
Mounting Type:
Surface Mount
Maximum Operating Temperature:
+125 °C
Line Regulation:
50 ppm/V
Maximum Input Voltage:
20 V
Height:
1.498mm
Width:
3.988mm
Length:
5mm
Initial Accuracy:
±0.15 %
Package Type:
SOIC
Maximum Output Voltage:
2.5 V
Minimum Operating Temperature:
-40 °C
Nominal Voltage:
2.5V
Reference Type:
Fixed
Maximum Output Current:
100mA
Pin Count:
8
Topology:
Series
RoHs Compliant
Checking for live stock

This is Linear Technology Fixed Series Voltage Reference 2.5V ±0.15 % 8-Pin SOIC manufactured by Analog Devices. The manufacturer part number is LT1461DHS8-2.5#PBF. Load Regulation - 50 ppm/ma. The given dimensions of the product include 5.004 x 3.988 x 1.498mm. The product is available in surface mount configuration. It has a maximum operating temperature of +125 °c. Has a line regulation of 50 ppm/v. 20 v is the maximum voltage of the bespoke product. In addition, the height is 1.498mm. Furthermore, the product is 3.988mm wide. Its accurate length is 5mm. Its initial accuracy is approximately ±0.15 % . The package is a sort of soic. Its output voltage (maximum) includes 2.5 v. Whereas, the minimum operating temperature of the product is -40 °c. The nominal voltage of the product is 2.5v. The product has a reference of fixed type. Featuring 100ma of maximum output current. It contains 8 pins. Topology includes series.

pdf icon
LT1461, Micropower Precision Low Dropout Series Voltage Reference Family(Technical Reference)
pdf icon
Low Dropout Voltage Reference Datasheet(Technical Reference)
pdf icon
ESD Control Selection Guide V1(Technical Reference)

Reviews

  • Be the first to review.

FAQs

Yes. You can also search LT1461DHS8-2.5#PBF on website for other similar products.
We accept all major payment methods for all products including ET18371917. Please check your shopping cart at the time of order.
You can order Analog Devices brand products with LT1461DHS8-2.5#PBF directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Voltage References category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Linear Technology LT1461DHS8-2.5#PBF, Fixed Series Voltage Reference 2.5V, ±0.15 % 8-Pin, SOIC. You can also check on our website or by contacting our customer support team for further order details on Linear Technology LT1461DHS8-2.5#PBF, Fixed Series Voltage Reference 2.5V, ±0.15 % 8-Pin, SOIC.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET18371917 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Analog Devices" products on our website by using Enrgtech's Unique Manufacturing Part Number ET18371917.
Yes. We ship LT1461DHS8-2.5#PBF Internationally to many countries around the world.
