Category:
Power MOSFET
Dimensions:
10.29 x 9.65 x 4.83mm
Maximum Continuous Drain Current:
58 A
Transistor Material:
Si
Width:
9.65mm
Transistor Configuration:
Single
Maximum Drain Source Voltage:
100 V
Maximum Gate Threshold Voltage:
4V
Package Type:
D2PAK (TO-263)
Number of Elements per Chip:
1
Maximum Operating Temperature:
+175 °C
Typical Gate Charge @ Vgs:
13.5 nC @ 10 V
Channel Type:
N
Typical Input Capacitance @ Vds:
2700 pF@ 25 V
Length:
10.29mm
Pin Count:
3
Typical Turn-Off Delay Time:
70 ns
Mounting Type:
Surface Mount
Channel Mode:
Enhancement
Maximum Power Dissipation:
167 W
Maximum Gate Source Voltage:
-20 V, +20 V
Height:
4.83mm
Typical Turn-On Delay Time:
16 ns
Minimum Operating Temperature:
-55 °C
Maximum Drain Source Resistance:
18.2 mΩ
