Maximum Temperature:
+40°C
Minimum Temperature:
0°C
Application:
Gaming Machines, Networking, Notebook Computers, Portable Equipment
Protection Features:
Over Current Protection, Over Voltage Protection, Short Circuit Protection
Output Current Range:
0 → 1.875A
Maximum Input Current:
1.2A
Standards Met:
CE, CULus, EN 55022 Class B, EN 61000-3-2, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, FCC Class B
Input Connector:
2-Wire C8
Input Frequency Range:
47 → 63Hz
Efficiency:
88%
Energy Efficiency Level:
VI
Overall Length:
120mm
Overall Depth:
31.4mm
Number of Outputs:
1
Operating Temperature Range:
0 → +40 °C
Rated Output Power:
45W
Ripple And Noise:
240mV Pk-Pk
Output Voltage Rating:
24 V dc
Special Features:
Class B EMI, Low Cost, Low Profile Design, Non-Vented, Spill-Proof Case
Power Signal Conversion Type:
AC-DC
Overall Dimensions:
120 x 50.35 x 31.4mm
Weight:
250g
Mounting Type:
Desktop
Series:
PSAC45W
Input Voltage Range:
89 → 270 V ac
Cable Length:
1500mm
Output Connection Type:
DC Plug
Overall Width:
50.35mm
