Maximum Temperature:
+45°C
Minimum Temperature:
0°C
Regulator Type:
Switched Mode Power Supply
Application:
Industrial
MTBF:
200h
Protection Features:
Over Voltage Protection, Overload Protection
Output Current Range:
Maximum of 5000mA
Maximum Input Current:
600mA
Standards Met:
AUS, CE Certified, CULus Listed, EN 55022, EN 55024, ENEC22, EU, IEC 60065, IEC 60335-1, IEC 60950, JPN, PSE, SIQ, USA
Input Connector:
IEC 60320-C8
Input Frequency Range:
50 → 60Hz
Efficiency:
87%
Energy Efficiency Level:
VI
Overall Length:
90mm
Overall Depth:
32mm
Number of Outputs:
1
Operating Temperature Range:
0 → +45 °C
Rated Output Power:
25W
Ripple And Noise:
150mV Pk-Pk
Output Voltage Rating:
5 V dc
Special Features:
Continuously Short Circuit Proof, Efficiency Level VI, Over Voltage Protection, Overload Protection
Power Signal Conversion Type:
AC-DC
Overall Dimensions:
90 x 55 x 32mm
Weight:
187g
Mounting Type:
Desktop
Series:
FW8030/DT
Input Voltage Range:
100 → 240 V ac
Overall Width:
55mm
