This is Dual 2-Input NOR Logic Gate 2 → 6 V 14-Pin SOP manufactured by Toshiba. The manufacturer part number is TC74HC4002AF(F). The given dimensions of the product include 10.3 x 5.3 x 1.5mm. The logic family is hc. Furthermore, the product is 5.3mm wide. On the other hand, it is featured with 5.2ma of max. low level output current. While a -5.2ma of maximum high level output current. It provides up to 17 ns @ 6 v, 20 ns @ 4.5 v, 100 ns @ 2 v maximum propagation delay time. While its minimum operating supply voltage is 2 v. The package is a sort of sop. It has a maximum operating temperature of +85 °c. It contains 2 inputs per gate . Its accurate length is 10.3mm. It contains 14 pins. It has 6 v maximum operating supply voltage. The product is available in surface mount configuration. The primary function of logic includes nor. In addition, the height is 1.5mm. Whereas, the minimum operating temperature of the product is -40 °c. Schmitt Trigger Input - no. It carries 2 elements. Features 50pf of propagation delay test condition.
For more information please check the datasheets.
