Dimensions:
2.9 x 1.6 x 0.7mm
Maximum Continuous Drain Current:
5.2 A
Transistor Material:
Si
Width:
1.6mm
Transistor Configuration:
Single
Maximum Drain Source Voltage:
20 V
Maximum Gate Threshold Voltage:
1V
Maximum Drain Source Resistance:
137 mΩ
Package Type:
TSM
Number of Elements per Chip:
1
Maximum Operating Temperature:
+150 °C
Typical Gate Charge @ Vgs:
8.1 nC @ 4.5 V
Channel Type:
P
Typical Input Capacitance @ Vds:
640 pF@ -10 V
Length:
2.9mm
Pin Count:
3
Typical Turn-Off Delay Time:
102 ns
Mounting Type:
Surface Mount
Channel Mode:
Enhancement
Maximum Power Dissipation:
1.25 W
Series:
SSM3
Maximum Gate Source Voltage:
±8 V
Height:
0.7mm
Typical Turn-On Delay Time:
32 ns
Minimum Operating Temperature:
-55 °C
