Category:
Power MOSFET
Dimensions:
6.7 x 3.7 x 1.7mm
Maximum Continuous Drain Current:
3 A
Transistor Material:
Si
Width:
3.7mm
Transistor Configuration:
Single
Maximum Drain Source Voltage:
30 V
Maximum Gate Threshold Voltage:
2.8V
Package Type:
SC-73
Number of Elements per Chip:
1
Minimum Gate Threshold Voltage:
1V
Maximum Operating Temperature:
+150 °C
Typical Gate Charge @ Vgs:
10 nC @ 10 V
Channel Type:
P
Typical Input Capacitance @ Vds:
250 pF@ 20 V
Length:
6.7mm
Pin Count:
4
Mounting Type:
Surface Mount
Channel Mode:
Enhancement
Maximum Power Dissipation:
1.65 W
Maximum Gate Source Voltage:
±20 V
Height:
1.7mm
Minimum Operating Temperature:
-65 °C
Maximum Drain Source Resistance:
250 mΩ
